型号及指标 Model & Specifications
|
型号 Model |
频率 Freq （GHz） |
驻波比 VSWR |
插损 IL (dB) |
接头 Connector |
|
XB-BNC-□□ |
DC-4GHz |
1.3 |
0.2 |
FF/FM/MM |
|
XB-7/16-□□ |
DC-6GHz |
1.3 |
0.2 |
FF/FM/MM |
|
XB-TNC-□□ |
DC-11GHz |
1.3 |
0.3 |
FF/FM/MM |
|
XB-N-□□ |
DC-18GHz |
1.3 |
0.3 |
FF/FM/MM |
|
XB-SMA-□□ |
DC-26.5GHz |
1.25 |
0.3 |
FF/FM/MM |
|
XB-APC3.5-□□ |
DC-30GHz |
1.2 |
0.2 |
FF/FM/MM |
|
XB-K2.92-□□ |
DC-40GHz |
1.2 |
0.2 |
FF/FM/MM |
|
XB-OS2.4-□□ |
DC-50GHz |
1.25 |
0.3 |
FF/FM/MM |
|
XB-V1.85-□□ |
DC-63GHz |
1.3 |
0.4 |
FF/FM/MM |
|
|
||||
|
XB-BNC/N-□□ |
DC-4GHz |
1.25 |
0.2 |
FF/FM/MM |
|
XB-7/16/N-□□ |
DC-6GHz |
1.3 |
0.2 |
FF/FM/MM |
|
XB-TNC/N-□□ |
DC-11GHz |
1.3 |
0.3 |
FF/FM/MM |
|
XB-N/SMA-□□ |
DC-18GHz |
1.3 |
0.3 |
FF/FM/MM |
|
XB-K2.92/APC3.5-□□ |
DC-30GHz |
1.25 |
0.2 |
FF/FM/MM |
|
XB-OS2.4/APC3.5-□□ |
DC-30GHz |
1.25 |
0.2 |
FF/FM/MM |
|
XB-K2.92/OS2.4-□□ |
DC-40GHz |
1.25 |
0.2 |
FF/FM/MM |
※ 以上只是常规产品，其它品种的频率覆盖范围可从 1.45-110GHz，波导型号可从WR510（BJ18）～ WR10（BJ900）
※ Other Products: F=1.45 ～ 110GHz, Waveguide WR510 (BJ18) ～ WR10 (BJ900)
