型号及指标 Model & Specifications
|
型号 Model |
频率范围 Freq (GHz) |
法兰 Flange |
驻波 VSWR |
接头 Connector |
|
XB-WAD84-□ |
0.84-2 |
WRD84 |
≤1.5 |
N |
|
XB-WAD150-□ |
1.5-3.6 |
WRD150 |
≤1.5 |
N |
|
XB-WAD200-□ |
2-4.8 |
WRD200 |
≤1.5 |
N |
|
XB-WAD250-□ |
2.6-7.8 |
WRD250 |
≤1.5 |
N |
|
XB-WAD350-□ |
3.5-8.2 |
WRD350 |
≤1.5 |
N |
|
XB-WAD475-□ |
4.75-11 |
WRD475 |
≤1.5 |
N |
|
XB-WAD500-□ |
5-18 |
WRD500 |
≤1.4 |
SMA |
|
XB-WAD580-□ |
5.8-16 |
WRD580 |
≤1.4 |
SMA |
|
XB-WAD650-□ |
6.5-18.0 |
WRD650 |
≤1.4 |
N / SMA |
|
XB-WAD750-□ |
7.5-18.0 |
WRD750 |
≤1.4 |
N / SMA |
|
XB-WAD700-□ |
7-18.5 |
WRD700 |
≤1.4 |
SMA |
|
XB-WAD1100-□ |
11-26.5 |
WRD1100 |
≤1.5 |
K |
|
XB-WAD1800-□ |
18-40 |
WRD1800 |
≤1.5 |
K |
※ 以上只是常规产品，其它品种的频率覆盖范围可从 1.45-110GHz，波导型号可从WR510（BJ18）～ WR10（BJ900）
※ Other Products: F=1.45 ～ 110GHz, Waveguide WR510 (BJ18) ～ WR10 (BJ900)
